Configure your custom shade sail
Access the configurator and create
your custom sail online

Shade sail with wall profile
Access the configurator and create your sail
with a straight side and aluminum profile

Discover our ROLL-UP SHADE SAILS
Solaria Furl - premium roll-up shade sails with a radial cut

Reference

Solaria Breathable Our best radial cut shade sail

5 (3) |

verified reviews

Solaria Breathable is a radial-cut shade sail made from breathable Meshnet® HDPE 320 fabric that protects against intense heat and hail and shelters against UV rays and strong winds.

It is an ideal solution for covering outdoor areas such as gardens, terraces, penthouses and parking spaces.

Radial cut: better distribution of tension and wind resistance up to 65 km/h
Zigzag seams with triple stitch point: increased elasticity and resistance to traction
Convertible into a roll-up sail: with the exclusive Furl system
Adjustable straps: even distribution of tension across the entire surface

Questions about the product or design?

Follow our measurement guide for a perfect result

Colour: Ivory Meshnet®

Size under tension: rectangle 3x4m

Size chart

The measures of the sail
The indicated sizes refer to the distance between the rings of the correctly tensioned sail.
We always indicate the "size under tension", that is the definitive measure that the sail takes after approx. 14-21 days after assembly.
At this link you can read more about the slight initial stretch of the fabric

Concavity and measures in the center of the sail
All shade sails have a slightly concave shape. This concavity of the sides ensures that the tension applied to the corners optimally reaches the center of the sail.

For Saill and Solaria sails the concavity of the sides is 2% of their length, for EasyShade sails it is 5%.

Due to the concave shape, the sail is slightly narrower in the center.
For example, a 5x5m square Solaria sail has 4 sides of 500cm and is exactly 480cm wide in the center (corresponds to a concave indentation of exactly 10cm on each side).

Distance between the anchor point and the angle of the sail Please provide approx. 35cm-100cm clearance from each sail corner to the associated anchorage point.

This distance is essential for proper tension of the sail.

immagine_ingombri

Example:
A sail with the dimensions 4 x 6m requires the following surfaces:

At least 4,7m x 6,7m = (4m sail + 0,35m + 0,35m) x (6m sail + 0,35m + 0,35m)
Maximum 6 x 8m = (4m sail + 1m + 1m) x (6m sail + 1m + 1m)

Too small an area provides too little space for attaching the attachment accessory.
If the distances are too long, the sail becomes unstable in strong gusts of wind.

Size chart square / rectangle sails

Sail size	Area min.	Area max.
3x2m	3.7x2.7m	5x4m
3x3m	3.7x3.7m	5x5m
3x4m	3.7x4.7m	5x6m
3x5m	3.7x5.7m	5x7m
3x6m	3.7x6.7m	5x8m
3.5x4.5m	4.2x5.2m	5.5x6.5m
3.5x5.5m	4.2x6.2m	5.5x7.5m
4x4m	4.7x4.7m	6x6m
4x5m	4.7x5.7m	6x7m
4x6m	4.7x6.7m	6x8m
4.5x5.5m	5.2x6.2m	6.5x7.5m
4.5x6.5m	5.2x7.2m	6.5x8.5m
5x5m	5.7x5.7m	7x7m
5.5x5.5m	6.2x6.2m	7.5x7.5m
5x6m	5.7x6.7m	7x8m

Size chart triangle sails

Sail size	Area min.	Area max.
3.6x3.6x3.6	4.3x4.3x4.3m	5.6x5.6x5.6m
4x4x4	4.7x4.7x4.7m	6x6x6m
4x4x5.66	4.7x4.7x6.36m	6.6x6.6x7.66m
5x5x7.07	5.7x5.7x7.77m	7x7x8.07m
5x5x5	5.7x5.7x5.7m	7x7x7m
6x6x6	6.7x6.7x6.7m	8x8x8m

-30% £679.00

£475.30

VAT included

Order now and receive it

with UPS Carbon Neutral

YOU CAN TRUST

Free design service
Delivery 24 / 48 hours
After-Sales Service

Description

Nautical Technology

RADIAL CUT

A technology born in the early '80s in the field of competitive sailing sails with the aim of making them high-performing and durable. The orientation of the cuts, the quantity of seams, and the type of stitches ensure the spread of force across the entire surface, making the radial-cut sail resistant to strong wind loads.

Advantages of radial cut:

Makes sails resistant to wind gusts up to 65 km/h
Provides an unmatched uniform tensioning
Ensures performance incomparable to the straight-cut cross cut
Reduces wear and tear deterioration

Learn more

Elasticity and Seal

ZIGZAG SEAMS WITH TRIPLE STITCH POINT

Studied and applied by our R&D department, the zigzag stitching with triple stitch point is designed to provide the sail with greater elasticity when subjected to tension. Working like an accordion, it manages to ensure maximum performance in terms of wind resistance and intense mechanical stress.

Advantages of zigzag seams with triple stitch point:

Increases elasticity of the fabric
Prevents tears or failures
Combined with technical thread, enhances sail performance

Convertible to Furling Sail

FURLER SYSTEM

The Furl system allows you to quickly and safely transform Solaria from fixed installation to manual furling. The oversized Furl in aluminum and 316 stainless steel is capable of withstanding strong twists even under extreme wind loads and ensures quick and smooth openings and closures.

Advantages of the Furler system:

Opening and closing maneuvers in less than 27 seconds
Nautical materials and technologies
Do-it-yourself installation without specialized labor

Furler Kit

Maanta Exclusive

ADJUSTABLE STRAPS

Two perimeter straps and one central strap, combined with multilayer reinforcements, ensure the maximum level of tension. The straps are manually adjustable to calibrate the tension of the sails at any time.

Advantages of adjustable straps:

Prevent sagging and tearing due to strong winds
Allow manual adjustment of tension
Reduce the formation of wrinkles that might form over time
Ensure greater stability of the sail

WHY CHOOSE SOLARIA

Available tailor-made

Solaria can also be designed and created independently thanks to the online configurator. The Maanta technical team is ready to assist you in the design of the perfect sail for your needs.

Meshnet® HDPE 320 Fabric

Meshnet® HDPE 320 fabric is extremely tensile and tension resistant. Depending on the coloration, it offers UV protection of up to 98% while ensuring an excellent heat shield from heat due to its thickness. Discover Meshnet®

Reinforced stitching

Five layers of technical fabric cover the corners of the sails, the points most stressed by wind traction and sail tension, making them more resistant.

316 Stainless steel plates

The 316 stainless steel reinforcement plates are part of the exclusive Maanta tensioning system, an essential innovation to evenly distribute tension on the sail and withstand the weather and wear.

Digital cut

The digital cutting table allows precision to the millimeter and at the same time, sealing the cutting area, preventing fraying or inaccuracies.

Made in Italy

From concept to realization, the Maanta crew follows the entire production process that ends with hand-sewn finishes by our seamstresses.

Quote

We help you design your perfect sail

FREE CUSTOM QUOTE

Finding the anchoring points and the right measurement, identifying the correct position in your outdoor area, guiding you in choosing the most suitable fabric, and delivering to you a customized quote for free. Maanta's technical team is ready to assist you in designing your perfect sail.

To assist you in the design, we only need:

A drawing of the area to be covered with measurements
An approximate indication of the budget for expenses
Some photos of the area of interest
Your details to create the personalized quote

Request your quote

Accessories

5 (13) |

verified reviews

Alu Simple

Pole for shade sails with variable height

431.2 £ 539 £

Discover

5 (7) |

verified reviews

Ulisse

Sail pole with 6 anchor points

247.2 £ 309 £

Discover

5 (5) |

verified reviews

EZ Mast

Significantly sturdy entry level shade sail pole

175.2 £ 219 £

Discover

5 (5) |

verified reviews

EZ Mast Stainless Steel

Stainless steel shade sail pole

367.2 £ 459 £

Discover

Fabric samples

Solaria and Solaria +Plus sail fabrics

0.7 £ 1 £

Discover

Wall Mounting Kit Muscle x3

Wall anchoring with pulleys

54 £ 60 £

Discover

Kit Furler

Transform your sail from fixed to roll-up

1214.1 £ 1349 £

Discover

5 (5) |

verified reviews

Solaria +Plus Breathable

The evolution of our best sail with radial cut

818.3 £ 1169 £

Discover

5 (10) |

verified reviews

Solaria Waterproof

Our best radial cut shade sail

545.3 £ 779 £

Discover

5 (5) |

verified reviews

Randa XL

Outdoor bean bag chair with a radial design

599 £ 599 £

Discover

Reviews

VERIFIED REVIEWS

Our platform requests reviews from customers about the purchase considering product quality, delivery time and service.

Sara B.

May 11

Excellent product

Very satisfied. High quality and professionalism. (translated from the original language)

Giulia D.

Mar 16

beautiful

the product corresponds to the description..technical stitching and perfect shading. we still have to assemble them but i am sure they will be perfect (translated from the original language)

Valeria S.

Feb 10

Solaria Breathable Shade

Beautiful and really good quality. Satisfied also to have bought a product made in Italy. (translated from the original language)

Data sheet

Meshnet® Ivory

Model	Solaria Breathable
Available Sizes	Standard and Custom through online configurator
Fabric Types	Meshnet® HDPE Breathable
Fabric Weight	Meshnet® 320 gr/sqm
Wind resistance	Up to 65 km/h
Tear Resistance	✓
Maximum Area	42 m²
Cut	Digital with Radial Design
Reinforcements	Enhanced with 5 layers
Plates	Marine Plates in Stainless Steel 316
Perimeter Straps	Adjustable grooved perimeter strap (load 800kg)
Stitching	ZigZag Triple Stitch with sealed seams
Warranty	4-years
Packaging and Storage	Cotton sail bag (also ideal for sail storage)
Box Dimensions	1 box maximum size 48x60x70 cm
Material Not Included	Poles, Anchoring Plates, Clips/Carabiners, Rope

Instructions & Info

HOW TO ASSEMBLE SOLARIA

Assembling Solaria is easy and does not require specialized labor or specific equipment. Follow the instructions in the assembly video or download the PDF guide. If you need additional support, our technical office is at your disposal.

Technical sheet, package contents, assembly guide, and warranty.

Download the PDF guide

FAQ

Breathable Solaria is not waterproof unlike waterproof Solaria, which through its sealed seams does not allow water to seep through.

Solaria Breathable thanks to the strong Meshnet® 320 fabric is hail-resistant and especially suitable for very windy areas.

It is the only radial-cut sail that incorporates more than 10 technologies combined with the recognizable design. It also offers an excellent heat shield, providing airy, breezy shade!

The breathable sail is ideal for those who want to make full use of their outdoor space.

The breathable sail creates an airy shade area that is sheltered from UV rays. At the same time, it protects against hail and wind gusts.

The breathable sail is an ideal solution for covering outdoor parking spaces. The strength of Meshnet® fabric withstands the most extreme stresses such as hail and strong winds.

Solaria Breathable is perfect for covering open spaces such as gardens, terraces and penthouses.

Adjustable perimeter webbing is part of Maanta's sail tensioning system.

The webbing, attached to the corner plates, is manually adjustable and allows the perfect degree of tension to be achieved so that the sail awnings are resistant to heavy mechanical stresses such as hail and wind.
