Pole Stabilisation Kit Rear tensioning system for shade sail pole stability

The rear stabilisation system is a technical accessory that stabilises the pole of shade sails by counteracting the force generated by the sail under tension. It helps reduce pole flexing and improves the overall stability of the structure, especially in windy or rainy conditions.

We recommend using the rear stabilisation system with large shade sails (over 20 m²), in windy locations or in setups where the pole is under significant stress. It’s also ideal for anyone looking for a sturdier, longer-lasting installation. You can also purchase it at a later time if needed.

The rear stabilisation system should be fixed on the side opposite to the direction of the sail, ideally aligned with the exact point where the sail is anchored to the pole. The anchoring must be done on a solid surface such as concrete, perimeter walls or concrete footings.

Yes, the rear stabilisation system has been specifically designed to integrate perfectly with Maanta Alu Simple and Ulisse poles.

The rear stabilisation system must be fixed to a solid and stable surface. It can be anchored to a concrete floor, a dedicated footing or a wall, always using the included threaded rod and injection mortar. It’s important that the anchoring point is aligned with the pole and positioned opposite to the direction of the sail’s tension.

No, the kit already includes all the components needed for installation: it comes with a 6 mm rope, shackles, carabiners, threaded rod and integrated Muscle x3 system. No additional components are required, except for the injection mortar, which is not included and can be purchased separately here. You can always add the rear bracing system for poles at a later stage.

Absolutely not. The Muscle x3 tensioning system triples the force applied to the rope, allowing for high tension with minimal effort. It’s easy to use, even if you have no technical experience.

Yes. One of the key features of the Maanta rear stabilisation system is the ability to make adjustments even after installation – ideal in case of ground settling or seasonal changes affecting the structure.

The design is technical yet discreet. The rope is also available in two colours (beige or silver) to blend seamlessly with Maanta poles, the shade sail fabric and the surrounding environment.
